Motor controller306006
Publisher: Wuxi Kuanhui Technology Co., Ltd. release time:2021-12-13 16:35:59 hit count:112 shut down

 Product Introduction

 M6 is a 24V DC motor driver specially designed by Wuxi Kuanhui for high-altitude vehicles. The product is manufactured with fine art, reliable quality, waterproof, dustproof, heat dissipation and manufacturability. This product can also directly replace the existing ones in the market. Similar products, and superior in performance.


 Features

    This product adopts advanced technology (TOLL) high-current power MOSFET control, which has a high current overload capacity;
Use a dedicated current sensor to monitor the output current in real time, which can realize precise current control and over-current protection;
   This product adopts a double waterproof design to ensure long-term and durable waterproof reliability. Waterproof grade IP67

technical parameter

Rated input voltage: 24V


2 minutes working current: 300A


1 hour working current: 200A

PWM working frequency: 15KHz


Accelerator type: Voltage type accelerator

Insulation strength: 500VAC

Output current reduction opening temperature: 85℃
